Inlet pressure P1 [bar(a)]

Inlet temperature T1 [C]

Inlet rel. humidity rH [%]

Discharge pressure P2 [bar(a)]

Calculate compressor
works (HIS) in [J/kg]

A compressor is designed to handle a certain amount of work [J/kg]. The height of system pressure that this avaialble amount of work can handle is depending on the suction temperature of the medium (here air). After you have put in the design values on top and calculated the maximum DESIGN works (HIS) of the blower, you can see the effect of suction air temperature on the amount of system pressure teh blower can handle, by moving the slider below

Suction temperature T1 = °C

Design Works

System pressure the blower can handle:
